QH69 Series Shot Blasting Machine for Structural Steel
It is used for cleaning metal surfaces. It can also remove oxide scale and rust from different kinds of steel profiles.
Product Details
With automatic self-feeding of workpieces, it meets the requirements of production lines.It is applied to industries such as shipbuilding, automobiles,motorcycles, bridges, and machinery manufacturing.It is mainly used for stress relief and surface rust removal of large steel structures, H-beams, and similar components.
Product Specifications
| Model | Workpiece Max. Size mm (L×W×H) | Max. Opening Size mm (W×H) | Cleaning Speed (m/min) | Blasting Wheel Power (kW) | Blasting Wheel Quantity (set) | Roller Conveyor Length (mm) | Total Power (kW) |
|---|---|---|---|---|---|---|---|
| QH698 | 12000 × 800 × 600 | 1000 × 800 | 1.0–2.0 | 11 | 4 | 12 × 1000 = 12000 | ≈ 80 |
| 12000 × 800 × 1000 | 1000 × 1200 | 1.0–2.0 | 11 | 6 | 12 × 1000 = 12000 | ≈ 110 | |
| 12000 × 800 × 1400 | 1000 × 1600 | 1.0–2.0 | 11 | 8 | 12 × 1000 = 12000 | ≈ 157 | |
| 12000 × 800 × 1800 | 1000 × 2000 | 0.5–2.0 | 11 | 8 | 12 × 1000 = 12000 | ≈ 157 | |
| QH6910 | 12000 × 1000 × 600 | 1200 × 800 | 0.5–1.5 | 11 | 4 | 12 × 1000 = 12000 | ≈ 107 |
| 12000 × 1000 × 1000 | 1200 × 1200 | 0.5–1.5 | 11 | 6 | 12 × 1000 = 12000 | ≈ 160 | |
| 12000 × 1000 × 1400 | 1200 × 1600 | 0.5–1.5 | 11 | 8 | 12 × 1000 = 12000 | ≈ 166 | |
| 12000 × 1000 × 1800 | 1200 × 2000 | 0.5–1.5 | 11 | 8 | 12 × 1000 = 12000 | ≈ 193 | |
| QH6912 | 12000 × 1200 × 600 | 1400 × 800 | 0.5–1.5 | 11 | 4 | 12 × 1000 = 12000 | ≈ 85 |
| 12000 × 1200 × 1000 | 1400 × 1200 | 0.5–1.5 | 11 | 6 | 12 × 1000 = 12000 | ≈ 110 | |
| 12000 × 1200 × 1400 | 1400 × 1600 | 0.5–1.5 | 11 | 8 | 12 × 1000 = 12000 | ≈ 158 | |
| 12000 × 1200 × 1800 | 1400 × 2000 | 0.5–1.5 | 11 | 8 | 12 × 1000 = 12000 | ≈ 158 | |
| QH6915 | 12000 × 1500 × 600 | 1700 × 800 | 0.5–1.5 | 11 | 4 | 12 × 1000 = 12000 | ≈ 89 |
| 12000 × 1500 × 1000 | 1700 × 1200 | 0.5–1.5 | 11 | 6 | 12 × 1000 = 12000 | ≈ 114 | |
| 12000 × 1500 × 1400 | 1700 × 1600 | 0.5–1.5 | 11 | 6 | 12 × 1000 = 12000 | ≈ 121 | |
| 12000 × 1500 × 1800 | 1700 × 2000 | 0.5–1.5 | 11 | 8 | 12 × 1000 = 12000 | ≈ 150 |
Product Applications
lt aoplies to shippinq, car motorccie bnidae, machineindustriesetclt is mainiv used for elioinatina the stressand surface removing nust of large steel structure Hbeam and soon
